VBA10201-R.3577.A
- Ｄ5 ･ -
DC/DC PCB Unit
Yellow:Power Drive PCB
Red:Power Drive PCB
Green:Power Drive PCB
Blue:Power Drive PCB
Black:Power Drive PCB
Pink:Battery Contact
Black:Battery Contact
FPC from the Power Drive
Pink:IF PCB
Pink: Main FPC
Black:IF PCB
#830x2
#732x2
Battery for backup
DC/DC PCB
