VBA10201-R.3577.A
- Ｄ7 ･ -
2. Removal of Screws
3. Removal of wires and FPCs
#665x2
#835x2
#628
Top Cover FPC
Brown: Top cover GND
E y e p i e c e f r a m e
B271
