VBA10201-R.3577.A
- Ａ35 ･ -
2. Assemble the CF Card Cover Unit
End A of spring of CF card cover
Hole A
①
Insert the end A of hinge spring into the hole A on the back cover.
②
Bend the hinge in an arrow direction and then x it with the 2 screws #826.
#826x2
#514
Hinge
