VBA10201-R.3577.A
- Ｄ9 ･ -
2. FRONT BODY
Shutter
1. Mirror-up, Removal of soldering bridges
Remove the soldering bridges between the
shutter FPC and the SQ FPC.
• Turn the white gear on the SQ PCB in an
arrow direction for the mirror-up.
Separation of Front Body and Rear body
#619x2
#619x2
#608x2
#634
To Next Page
