VBA10201-R.3577.A
- Ｄ16 ･ -
Horizontal AF Lever Unit
Bayonet Mount
#185
B193
#629
#756
#1006
Remove the soldering bridge
between th e le ns contact
mold and the lens contact
FPC.
　
Yellow:Fmin PCB
Black:Fmin PCB
#114
B113
#134
#613
#133
B131
#623
#112
#111
#635
#634x4
#655
