ADJUSTMENT THROUGH PC
● If the camera is connected to a personal computer, connect the MC-31 (J19109) to the RS232C connector
of the personal computer as shown in the following gure and connect the communication tool (J61198) to the
camera.
O
N
OFF
s
W
B
A
QU
A
L
IS
O
FO
R
M
AT
M
S
P
S
C
To RS232C
D 1 0 0
Battery tool
J61197
Se t v a lu e s f or th e
s t a b i l i z e d p o w e r
supply
8.5V、0.3Ω
5.0A
or, AC dapter
ＥＨ
-5
J19109
9 p i n - 2 5 p i n a d a p t e r i s
necessary for a computer
w i t h 9 - p i n R S - 2 3 2 C
terminal.
RJ is not available
J61198
●
For the AE inspection and the M1/4000 adjust-
ment, use the light receiver for APS and the D100
ligh receive adapter (J61199) as shown in Figure
since the size of D100 shutter is APS size. .
J61199
Light Receive Adapter
J19042E
T.V. Measuring Adapter
Adapter for former type of cameras
J19042D
★ J18340
Adj. FD for D100 IBM 3.5
Shutter tester
Main FPC
★：
Newly established tool
★
★
★
N o t e ) R e m o v e t h e * m a r k e d
FPC(Refer to page A33)from the
slider when connecting to PC by
communication tool(J61198) .
IF without removing the Memory
compression PCB.
To Next Page
