Chapter 5 Laser Unit
5.1 Overview of the Laser Units
1-99
(11) AOTF/PC connector
This connector is used to control AOTF of the LU4A
four-laser module A. (Do not use in this system.)
(12) Interlock cable connectors
CONF: Do not use in this system.
MIC: This is a connector for the interlock cable to connect
the microscope.
TIRF: This is a connector for a cable to connect the laser
safety cover.
For using the PAU system, be sure to connect a pin-jack
connector supplied with the TI－LU4SU shutter unit.
(13) LUSU connector
This is a cable to connect the TI-LU4SU shutter unit.
(14) USB connector
This connector is for a USB cable to connect a PC.
(15) LD connector
This connector is for future expansion. (Do not use in this
system. Otherwise, a malfunction occurs.)
Precautions when handling the laser unit
• The laser head and the optical fiber are precisely aligned in these units.
Avoid subjecting the laser head or optical fiber to vibration or shock. Contact the distributor if
you need to remove the laser head from the unit due to laser malfunction or other reasons.
