Nikon Eclipse TI-TIRF-E User Manual

Chapter 5 Laser Unit
5.5 Setting Up the LU-LR Four-laser PS Rack
1-202
Position of laser power supplies
1. Positions of laser power supplies
(1) Ar, HeNe, Laser diode x 2
Figure 5.5-10
(2) Ar, DPSS, Laser diode x 2
Figure 5.5-11
[1] Ar laser
[3] HeNe laser
[2] Laser diodes
Control box of LU-LR
four-laser PS rack
Front
Rear
[1] Ar laser
Control box of LU-LR
four-laser PS rack
Front
Rear
[4] DPSS laser (controller)
[5] DPSS laser (power supply)
[2] Laser diodes
