Nikon Eclipse TI-TIRF-E User Manual

Chapter 5 Laser Unit
5.5 Setting Up the LU-LR Four-laser PS Rack
1-203
(3) DPSS, HeNe, Laser diode x 2
Figure 5.5-12
(4) DPSS x 2, Laser diode x 2
Figure 5.5-13
[4] DPSS laser (controller)
[3] HeNe laser
[2] Laser diodes
Control box of LU-LR
four-laser PS rack
Front
Rear
[5] DPSS laser (power supply)
[4] DPSS laser (controller)
[4] DPSS laser
(controller)
[2] Laser diodes
Control box of LU-LR
four-laser PS rack
Front
Rear
[5] DPSS laser (power supply)
[5] DPSS laser (power supply)
