Chapter 6 Connection between the Laser Unit and the Microscope
6.1 Setting and Connecting the TI-LUSU Shutter Unit
1-220
2 r command: Data request command
Table 6.1-4
r command
a: Normal
response
n: Error response
Description
rTSR
aTSR(1)
nTSR(6)
The command reads the shutter condition.
(1): [0] means all shutters are closed. [1] to [3] means the shutter of the
number is open.
(6): Error code
* The rTSR command is disabled in the shutter independent control
mode.
rTTS(1)
aTTS(2)
nTTS(6)
The command reads the shutter open time setting.
(1): [1-3] Shutter number
(2): [0000-1000] Time setting
(6): Error code
rTES
aTES(3)
nTES(6)
The command reads the open/close conditions of the eyepiece tube
optical path and the safety cover.
(3): [1] means that either of the binocular route or the safety cover is
open. [0] means both are closed.
(6): Error code
* The safety cover open/close condition is detected only for the
TIRF/motorized TIRF illuminator system.
rTSW
aTSW(4)
nTSW(6)
The command reads the setting for the laser open/close switch on the
control panel.
(4): [1] Enabled, [0] Disabled
(6): Error code
rVER
aVER(5)
nVER(6)
The command reads the program version.
(5): V*.** (Five characters. “*” is a numeral. Example: V1.00)
(6): Error code
rPNM
aPNM(5)
nPNM(6)
The command reads the program name.
(5): T-LUSU
(6): Error code
To Next Page
