Chapter 6 Connection between the Laser Unit and the Microscope
6.1 Setting and Connecting the TI-LUSU Shutter Unit
1-221
(2) Shutter independent control commands
The following commands are enabled when the TI-LUSU shutter unit is set to the shutter independent control
mode.
Two or more shutters can be opened at a time.
1 c command: Operation, control, and data setting command
Table 6.1-5
c command
o: Normal
response
n: Error response
Description
cTSD(2)
oTSD
nTSD(6)
The command opens/closes the shutter 1st, 2nd, and 3rd at a time
independently.
(2): [0]: 1st shutter closed, 2nd shutter closed, 3rd shutter closed
[1]: 1st shutter open, 2nd shutter closed, 3rd shutter closed
[2]: 1st shutter closed, 2nd shutter open, 3rd shutter closed
[3]: 1st shutter open, 2nd shutter open, 3rd shutter closed
[4]: 1st shutter closed, 2nd shutter closed, 3rd shutter open
[5]: 1st shutter open, 2nd shutter closed, 3rd shutter open
[6]: 1st shutter closed, 2nd shutter open, 3rd shutter open
[7]: 1st shutter open, 2nd shutter open, 3rd shutter open
(6): Error code
cTIO(3)
oTIO
nTIO(6)
The command opens the specified shutter.
(3): [1-3] Shutter number
(6): Error code
cTIC(4)
oTIC
nTIC(6)
The command closes the specified shutter.
(This command is enabled only when the shutter independent control
mode.)
(3): [1-3] Shutter number
(6): Error code
2 r command: Data request command
Table 6.1-6
r command
a: Normal
response
n: Error response
Description
rTEX
aTEX(1)
nTEX(6)
The command reads the condition of the shutter independent control
mode.
(1): [1] Enabled, [0] Disabled (standard condition)
(6): Error code
rTSD
aTSD(2)
nTSD (6)
The command reads the shutter condition.
(2): [0]: 1st shutter closed, 2nd shutter closed, 3rd shutter closed
[1]: 1st shutter open, 2nd shutter closed, 3rd shutter closed
[2]: 1st shutter closed, 2nd shutter open, 3rd shutter closed
[3]: 1st shutter open, 2nd shutter open, 3rd shutter closed
[4]: 1st shutter closed, 2nd shutter closed, 3rd shutter open
[5]: 1st shutter open, 2nd shutter closed, 3rd shutter open
[6]: 1st shutter closed, 2nd shutter open, 3rd shutter open
[7]: 1st shutter open, 2nd shutter open, 3rd shutter open
(6): Error code
