Chapter 1 System Configurations and Part Names
1.4 Name of Each Part
2-21
Four-laser PS rack (LU-LR)
Front view
Rear view
Figure 1.4-16
(1) EMISSION laser indicator
(2) POWER laser indicator
(3) EMISSION key switch
(4) Power switch
(5) INTERLOCK connector
(6) Cooling fan
(7) Power breaker for 15 A line
(8) Power breaker for 5 A line
(9) Caution label
(10) Name plate for 15 A line ratings
(11) Name plate for 5 A line ratings
(12) AC inlet for 15 A line
(13) AC inlet for 5 A line
(5)
(11)
(6)
(7)
(13)
(1)
(2)
(3)
(4)
(9)
(10)
(12)
(8)
To Next Page
