30 - Solution System 55Service Manual – SC250, Scrubtec 334, MA 30
Solution Dispenser Cleaning
1. Ensure that the machine is off.
2. Remove the tanks container from the machine body using the handle.
3. Lift the machine body to access the lower part of the cleaning deck.
4. Remove the cylindrical brush.
5. Disassemble the solution dispensers (A) and clean them with water and detergent, then rinse and
reassemble in the corresponding housings.
Figure 5
A
A
