30 - Solution System 59Service Manual – SC250, Scrubtec 334, MA 30
Removal and Installation
Solution Tank Valve
1. Remove the tank assembly from the machine.
2. Working at the workbench, rotate the tank assembly and
3. Remove the 2 screws (A), remove the valve (B) and retain the gasket (C) for reuse.
Figure 6
C
B A
