Nilfisk-Advance Advance SC250

30 - Solution System 60Service Manual – SC250, Scrubtec 334, MA 30
Water Pump
Removal
1. Remove the tank assembly from the machine.
2. Open the rear cover and remove the battery.
3. Remove the 7 caps (A) and remove the 7 screws (B), then remove the upper cover from the machine body
(C).
Figure 7
A
B
B
B
B
B
B
B
C
A
A
A
A
A
A
4. Disconnect the connection (D) and remove the Water pump (E), retaining the brackets and hoses for
reuse.
Figure 8
D
F
E
Installation
5. Install the components by performing the removal procedure in reverse, ensuring you respect the ow
direction arrow (F) on the Water pump.
