38 - Squeegee System 83Service Manual – SC250, Scrubtec 334, MA 30
Vacuum Duct (continues)
10. Adjust squeegee lifting: Press the lifting lever and stop it with the orange push-button
11. The minimum height of the lifting bar must be ≥ 0.7 in (≥ 18 mm) (O). Adjust with the nut and locknut
(N).
Figure 10
O
N
0.7 in (18 mm)
0.7 in (18 mm)
