40 - Recovery System 95Service Manual – SC250, Scrubtec 334, MA 30
Vacuum System Motor (continues)
13. Save the gaskets (M) and (N).
Figure 14
N
M
14. Remove the save the clamp (O) and the dividing sponge (P), then disconnect the connections (Q).
Figure 15
Q
O
P
15. Clean the inside of the containers to remove any dirt which has accumulated, and check all gaskets for
wear; replace if necessary.
