NKE MULTIDISPLAY - USE OF THE MULTIGRAPHIC AS MULTIFUNCTION DISPLAY; SETTING PARAMETERS

Page 11/55 68_Afficheur_Multidisplay_um_UK_11
2.4 USE OF THE MULTIDISPLAY AS MULTIFUNCTION DISPLAY
Multidisplay is a multifunction display from the TOPLINE range of products. It
connects to the TOPLINE bus on your system and displays all data available on the
bus.
The keyboard, curser pad and scroll down menus make all aspects of the system
easy to use. Multidisplay facilitates control and use of your Topline system.
2.4.1 Edit an existing page
Once a page has been built (see paragraph 2.2), it can be edited to show temporary
or permanent changes.
2.4.2 Temporary modification
Temporary modification of a page allows data of your choice to be displayed without
saving a new layout.
• Browse through the page with .
• Highlight the data to modify and press .
• With choose the replacing data and press .
This modification has not been saved and the previous layout will return the next time
the system is powered on.
2.4.3 Permanant modification of a page constructed
Permanent modification allows modifying the page constructed and saving new
elements.
This is carried out in « parameters ». In order to modify a page, see chapter 2.2 page
building wizard.
2.5 SETTING PARAMETERS
Press and hold to display the main menu in which you select for the
«Parameters» page.
Use the up and down arrows of the pad
to select and to confirm.
