2.11.6 Pilot setup saving and recall
Up to 10 pilot setups can be saved and used at any time. For example, you can save
a setup for upwind conditions and another one for downwind.
Saving a pilot setup:
On the pilot page :
• Press , a window will appear.
• Select «Save config.» and press .
• With the up and down arrows , select the desired setup N° and press .
Then confirm with « Yes ».
• Give a name to your configuration and press « Ent » to confirm.
Recall a pilot setup:
On the pilot page:
• Press , a window will open.
• Select « Restore config. » and press .
• Select the desired back-up and press .
2.11.7 Pilot alarm
You can set two different alarms. One is for wind direction variation and another one
for low voltage.
- The first alarm is called “Wind/Head’ in the system. It measures variations in wind
direction when the pilot is in compass mode or heading in wind mode.
A value can be set up for the system to trigger the alarm. The default value is 15°.
The alarm will sound when the wind angle variation is greater than the set value for
more than 30 seconds in compass mode and when the heading variation is greater
than the set value for more than 30 seconds in wind mode. The Multidisplay will
display a message and sound beeps.
- The second alarm is called “Power Battery” in the system. It measures variations
in the charge level of the battery powering the pilot’s drive unit. The default value
is 8 V DC
The alarm is triggered when the voltage is lower than the set value. The Multigraphic
will display a message and sound beeps.
