Calibration of the Apparent Wind Angle:
• Select « Apparent Wind Angle » and press
.
• Choose « Calibration Wizard » and press .
• Select « Start » and press .
• Go on Starboard Tack and press . Wait and press .
• Go on the Port Tack and press . Wait and press .
• Repeat this procedure one more time.
• A window will open with the new Offset and ask to save the new one or keep
the old one. To save the new one select « yes » and confirm with .
2.6.3 Speed through water calibration wizard
The boat speed is calibrated with the speed over ground as reference. You have to
sail 0.5 nM on a constant heading and then sail back (180°) the same distance. The
new calibration is processed from the current calibration value already saved (there
is no need to reset the calibration value to 1).
The COG (Course Over Ground) function must be displayed on the Topline network
to achieve the boat speed calibration.
Boat speed calibration:
• Select « Boat speed » and press .
• Choose « Calibration Wizard » and press .
• Select « Start » and press .
• When your heading and speed are approximately steady, press .
• Go about 0.5 Nm in those conditions and press .
• Make a U turn (Your current heading + 180°) and press .
• Hold your course at a constant speed during 0.5Nm. Once complete press
• A window will open and ask you to save the new factor. If satisfied, select “yes”
and save with .
