1 PRESENTATION
Thank you for purchasing the nke Multidisplay.
The Multidisplay features a 7 inch colour screen. A transflective polarizer enhances
daylight reading and integrated LED backlighting ensures clear readability at night.
The backlight intensity can be automatically adjusted or user adjusted.
The Multidisplay is a multifunction device that enables to:
• Control the nke Gyropilot2 or Pilote HR
• Display data from the sensors connected to the Topline bus in digital, analog
or graphic format and access to setup parameters and alarms.
• Interface to NMEA 183 devices to provide relevant data to the Topline bus.
2 USE
The Multidisplay doesn’t have an integrated keyboard, therefore it is necessary to
use a Pad (display or pilot) or a transmitter (display or pilot) in order to control the
display.
See Pad (display or pilot) or transmitter (display or pilot) manuals.
• PAGE
Successive presses will scroll through the pre-set data pages, the pilot page
and the setting page.
Press and hold (at least 3 seconds) to open the Menu page.
• OK
A single press confirms the current selection, or opens specific setup features
on some pages.
Press and hold (at least 3 seconds) to open the settings page for
backlighting, keyboard lock and stand-by mode.
• Cursor pad
Use for the selection of pages and menu options.
• . A,B,C,D (Pad display)
Those keys are shortcuts allowing access to different pages already programmed.
