• Choose « Standby time » and press .
• Modify the value with and save with .
Press and hold the “OK” key for 3 seconds to enter the Display Standby
setting menu. This can be done from any page.
2.5.6 Data logging : « stripcharts » settings
4 different sets of data can be logged simultaneously over a 48 hour period with a 15
seconds log rate. The logged data can be displayed on stripcharts on the
“Multidisplay”.
“stripcharts” settings process:
• In « parameters » select « Logger configuration » and press .
• Choose the logger to modify among the 4 available and press .
• With , modify the data and save with .
2.5.7 A,B,C,D keys configuration of the multifunction Pad
Keys A, B, C and D enable to display the pages programmed on all the displays.
In >> Parameters >> shortcuts configuration: select one of the keys to program and
press Choose in the list the page desired. By default no key is programmed.
2.5.8 Language selection
Your Multigraphic can be set to display menus in various languages.
Language setting process:
In « parameters » choose the language and press to save your choice.
2.5.9 Unit selection
The Multidisplay can be set to use various units for boat speed, depth, air
temperature, sea temperature and wind speed.
