Page 51/55 68_Afficheur_Multidisplay_um_UK_11
3.9 INSTALLATION AND CONFIGURATION OF THE GYROPILOT
Once the Gyropilot is installed, you need to configure the system. This consists of
teaching the pilot the rudder’s positions: place the rudder in the mid-ship position,
then at the starboard lock and then the port lock. These three rudder positions are
essential for the processor to run the drive unit.
Procedure :
• Press until you have access to the menu
• Select « pilot » and press .
• Select « Pilot setting » and follow the instructions displayed.
• Start by putting the rudder at mid-ship and press
• Push the rudder all the way to come to starboard and press , push the
rudder all the way to come to port and press
• Lastly, place the rudder at mid-ship and press . The Gyropilot initialisation
is complete.
Warning
The Gyropilot can only perform the automatic tack if the rudder ends are perfectly
symmetrical. While setting the rudder ends, check that this is the case. Port lock
to mid-ship and starboard lock to mid-ship must be the same.
