Page 7/55 68_Afficheur_Multidisplay_um_UK_11
Screen types available in landscape orientation :
1 line Displays 1 data
2 lines Displays 2 data
4 lines Displays 4 data
6 lines Displays 6 data
1+3 lines Displays one main data on the left and
superimposes 3 thumbnail data to the
right
4/4 page Displays 4 data on the same page and
alternates every 3 seconds with 4 other
data
1/1 page Displays 1 data and alternates with 1
other data every 3 seconds
XTE page Displays the waypoint difference at
Waypoint
Waypoint page Displays the Waypoint heading from the
COG
Screen types available in portrait orientation :
1 line Displays 1 data
2 lines Displays 2 data
3 lines Displays 3 data
4 lines Displays 4 data
Once you have made a choice, press to confirm.
4/4 et 1/1
This page is used to display 4 information that alternate with 4 other
information. It can also be used with feedback from racing software
(ADRENA, EXPEDITION,…) via the NMEA input after initialization (see
"NMEA initialization"). For example, the ADRENA software can be used to
feedback 8 information according to the phases of race, those information
can be read on these alternative pages. This information can be read on all
Multidisplay of the Topline network. The 8 channels available are named DYN1 to
DYN8.
