UDO LP400 User Guide
_____________________________________________________________________________________________________
LP400 User Guide (02/11) v5.2
2
Table of Contents
I. Product Description 3
II. Technical Support & Assistance 3
III. Switches, Indicators & Connections 4
IV. Setting-Up the UDO LP400 Printer 6
A. Installing Cables 6
B. Installing Vinyl Rolls 7
C. Installing Printer Ribbons 8
V. Loading UDO LP400 Software & Printer Driver 9
VI. Set-up Procedure for Printing on Continuous Vinyl 12
A. Default Settings & Adjustments 12
1. Label Dimensions 12
2. LP400 Printer Properties 13
a Advanced Setup 14
VII. Navigating the Toolbars 15
A. The Toolbox Toolbar 15
B. The Text Toolbar 16
C. The Alignment Toolbar 17
VIII. The Basics of Designing a Label 19
A. Inserting a Image 19
B. Inserting Text 20
C. Resizing & Positioning Objects 21
IX. Applications 21
A. Setting-Up Variables 21
B. Inversing 22
C. Rotating Text & Symbols 23
D. Curved Text 23
E. Importing Pictures 25
F. Multi-band Printing: Creating Large Signs & Labels 26
X. Common Applications 27
A. Directional Sign 27
B. Pipe Marker Sign 31
C. Inverted Text 35
D. Multi-band Printing 37
Troubleshooting 45
Maintenance 46
General Printer Specifications 47
