NMC UDO LP400 Series - General Printer Specifications

UDO LP400 User Guide
_____________________________________________________________________________________________________
LP400 User Guide (11/07)
47
General Printer Specifications
Print Technology Thermal Transfer
Resolution 203 DPI (dots per inch) 8 dots/mm
Maximum Print Width 4.10 in. (104mm)
Maximum Print Length 45 in. (1143mm)
Printer Speed 1” – 4” per second, default set for optimum
print quality at 1.5”/sec.
Onboard RAM 2 MB DRAM and 2MB Flash ROM
Media Type Vinyl, Polyester and Paper materials on
Continuous Roll and Die-Cut format
Label Roll Dimensions 4” Max. Label Width and 82’ Max. Roll
Length
Ribbon Type Resin, Wax, Wax/Resin
Ribbon Size 4 1/3” Width x 298’ Length (White 230’)
Interface USB 2.0
Dimensions W 7.3” x D 10.9” x H 6”
Weight 4.1 lbs.
Electrical FCC Class B, CE, UL and CUL approved.
Input 19 VAC or 24 VDC (min. 2.5A), 50/60
Hz
Operating Temperature
40
°~140°F (5° ~ 38°C)
Storage Temperature -40° ~ 140°F (-40° ~ 60°C)
Humidity 15 ~ 85% RH
Operating System Windows 95, 98, NT, NT4, 2000, XP,
Vista,7
Rotation 1° Increments
WEEE-RoHS Compliant Yes
Warranty 1 year Parts and Labor
