■ Standard service tools
Product Service Tool Photo Description Info
ACF-8 Universal Power
Supply
ACF-8 is used to power FPS-8 and
FLS-4S. ACF-8 has 6 Vdc and 2.1A
output.
FLS-4S POS Flash
Adapter
The Point of Sale (POS) flash is a
low-cost software upgrade tool.
This requires the XCS-1 cable and
ACP-8U for operation.
FPS-8 Flash Prommer The Flash Prommer FPS-8 is used
for heavy flash.
FPS-11 Parallel Flash
Prommer
Flashing several units(max 8) at
one time. The FPS-11 multi prom-
mer will replace FPS-8C
JBV-1 Docking Station The Docking Station and the Dock-
ing Station Adapter are needed for
Mbus, Fbus, RF, and audio connec-
tions
This setup allows connection
between flash prommers. When the
audio box is connected, it has to be
connected to the phone’s audio
connector. The Docking Station can
be powered by FPS-8 or external
power supply.
