Nokia 2650 - Component Parts List for RH-54, Updated Edition

Issue 2 06/2005 COMPANY CONFIDENTIAL 35
Copyright © 2005 Nokia. All Rights Reserved.
RH-53/54
3-Parts Lists and Component Layouts Nokia Customer Care
■ Component parts list for RH-54, updated edition
Note: For the latest parts lists and for product codes, always refer to the Service bulletin
Item Description Side XY
EMEA
APAC
CHINA
LTA
NAM
B200 CRYSTAL 32.768KHZ+-20PPM 12.5PF T J5 ●
B200 CRYSTAL 32.768KHZ+-20PPM 12.5PF T J5 ●
B600 CRYSTAL 26.OMHZ+-10PPM 15.5PF T D6 ●
C100 CHIPCAP X7R 6N8 K 25V 0402 T L5 ●
C101 CHIPCAP X7R 10N K 16V 0402 B M6 ●
C102 CHIPCAP X7R 10N K 16V 0402 B M6 ●
C103 CHIPTCAP 100u 6V3 70mOhm 3.5x2.8x2.0 T M7 ●
C105 CHIPCAP X7R 10N K 16V 0402 B M2 ●
C106 CHIPCAP X7R 10N K 16V 0402 B M2 ●
C123 CHIPCAP X7R 10N K 16V 0402 B M4 ●
C124 CHIPCAP X7R 10N K 16V 0402 B M4 ●
C151 CHIPCAP X7R 33N K 10V 0402 T J4 ●
C152 CHIPCAP X7R 33N K 10V 0402 T J3 ●
C153 CHIPCAP X7R 1N0 K 50V 0402 T K3 ●
C154 CHIPCAP X7R 1N0 K 50V 0402 T K4 ●
C157 CHIPCAP X5R 1U K 6V3 0603 T J2 ●
C158 CHIPCAP X5R 100N K 10V 0402 T K3 ●
C159 CHIPCAP X5R 100N K 10V 0402 T G5 ●
C168 CHIPCAP X5R 4U7 K 6V3 0805 T K4 ●
C170 CHIPCAP X7R 1N0 K 50V 0402 T K3 ●
C171 CHIPCAP X5R 4U7 K 6V3 0805 T K2 ●
C172 CHIPCAP X7R 1N0 K 50V 0402 T K3 ●
C173 CHIPCAP X7R 33N K 10V 0402 T J3 ●
C174 CHIPCAP X7R 33N K 10V 0402 T J3 ●
C180 CHIPCAP X5R 100N K 10V 0402 T G5 ●
C181 CHIPCAP X7R 100N K 16V 0603 T F4 ●
C182 CHIPCAP X5R 1U K 6V3 0603 T E5 ●
C183 CHIPCAP X7R 330P J 50V 0402 T F5 ●
C184 CHIPCAP NP0 100P J 50V 0402 T D5 ●
