Nokia E62 Service Manual

Parts lists
Mechanical spare parts list
Note: For Nokia product codes, please refer to the latest Service Bulletins on the Partner Website (PWS).
To ensure you are always using the latest codes, please check the PWS on a daily basis.
Bold = ASSY
"XXXXXXX" = VARIANTS
"-" = NOT AVAILABLE
"???????" = AVAILABLE AS SPARE PART
I0xx = ITEM codes for upper or mono block
I1xx = ITEM codes for hinge block
I2xx = ITEM codes for lower block
I3xx = ITEM codes for soldered spare parts on the upper, hinge or lower block and not exchangable
ITEM/
CIRCUIT
REF.
PART NO PART NAME QTY
I009 ??????? Window Assembly 040-012649 1
A1 ??????? A-Cover Assembly Silver 040-012429 1
I026 ??????? SCREW M1.6X5.7 DMD12402 TORX SILV 6
I008 ??????? SCREW M1.4X3.4 TORX PLUS 4IP 1
I007 ??????? Remform screw 1.8x8 1
I019 ??????? Battery Release Spring 1
I028 ??????? BLANK LABEL 29mmx18mm EXP65673 1
I021 ??????? Joystick Button 040-012658 1
I018 ??????? Battery Release Button 040-012946 1
I023 ??????? Joystick module tape 040-020164 1
I005 XXXXXXX Operator Logo painted Silver
040-012438
1
I027 XXXXXXX Antenna Lid, painted Silver 040-012654 1
I029 ??????? Battery Cover painted 040-012428 Silver 1
I012 ??????? EL-Dome Sheet 040-012655 1
I006 XXXXXXX KEYMAT PRINTED SILVER 040-021863 EN-
NL
1
I020 ??????? 1RE JOYSTICK ASSEMBLY 1
A2 ??????? Chassis Assembly 040-012635 1
I017 ??????? CONNECTOR HOUSING ASSEMBLY
040-015883
1
I022 ??????? Side Button Module 040-012642 1
I011 ??????? LCD AM 320x240 COG 16MCo Oxford 1
RM-88
Nokia Customer Care Parts Lists and Component Layouts
Page 2 –6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2006 Nokia. All rights reserved.

Nokia E62 Specifications

General

Panel type	LCD
Display resolution	320 x 240 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Processor frequency	0.235 GHz
Internal memory	80 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	S 60 UI
Form factor	Bar
Product color	Silver, White
Talk time (2G)	5.5 h
Battery capacity	1500 mAh
Standby time (2G)	330 h
2G standards	EDGE, GPRS
Keyboard layout	QWERTY
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Notes

Weight and Dimensions

Depth	14 mm
Width	69.7 mm
Height	177 mm
Weight	144 g
