CU-4 flash concept with FPS-10
Figure 32 CU-4 flash concept with FPS-10
Note: FPS-8 concept can also be used for flashing.
Description Type
SS-62/FS-5 Flash adapter
CU-4 Control unit
XCS-4 Modular cable
PCS-1 Power cable
FPS-10 Flash prommer box
Standard USB cable
Standard USB cable
PKD-1 SW security device
RM-88
Service Tools and Service Concepts Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 4 –15
Copyright © 2006 Nokia. All rights reserved.
