Installation
20 (72) © Nokia Corporation DN991456
Nokia Proprietary and Confidential Issue 3 en
Note
2. Lift the BTS out of the package and lay it horizontally. Do not stand the
BTS in a vertical position. Lay the BTS onto a clean or covered surface, not
directly onto the ground.
3. Save the packing cardboard from the package! The cardboard can be used
as a template for defining clearances around the BTS and for marking drill
hole locations for wall installation.
Check the contents of the BTS transportation package
1. Check the completeness of the delivery against the general contents
checklist in Table 4.
2. Visually inspect the cover of the BTS for any defects.
Remove the BTS cover
1. Inspect the cover visually for defects before removing it.
2. Open the lock on the bottom of the BTS using the key provided. The key
will remain in the lock whenever the lock is in the open position.
3. Loosen the cover by sliding it along the chassis to disengage the hooks
which hold it in place. Lift the cover off when the hooks are disengaged.
Check the BTS
1. Check the completeness of the delivery against the order specifications to
confirm that the delivery contains the correct unit types.
2. Visually inspect the interior of the BTS for any defects.
The unused connectors on the units are protected with rubber caps. Leave the cap
on the connector if the connector is not going to be used for cabling.
