List of figures
Figure 1. Contents of the Nokia MetroSite EDGE Base Station transportation
package when unpacked 22
Figure 2. Contents of the optional pole mounting kit 23
Figure 3. Connecting the antistatic wrist strap before removing any units 25
Figure 4. Removing the units 27
Figure 5. Mounting rack dimensions and screw holes 29
Figure 6. Cardboard template for aligning wall mounting screw holes 31
Figure 7. Wall mounting 33
Figure 8. Bracket blocks for pole mounting 35
Figure 9. Pre-assembling the pole brackets 36
Figure 10. Attaching the mounting rack and the pole brackets 38
Figure 11. Pole mounting with the small-pole mounting kit 40
Figure 12. Pole bracket pre-assembled (large-pole mounting kit) 42
Figure 13. Pole bracket pre-assembled (large-pole mounting kit) 43
Figure 14. Attaching the mounting rack and the pole brackets 45
Figure 15. Pole mounting with large-pole mounting kit 47
Figure 16. Displacing the sealing strip and removing the cable entry block
screws 52
Figure 17. Cable routing through the cable entry block 53
Figure 18. Grounding connector alternatives 54
Figure 19. Power supply unit and power connector alternatives 57
Figure 20. Cabling alternatives for the FC E1/T1 transmission unit 59
Figure 21. Cabling of the FXC E1 transmission unit 60
Figure 22. Cabling of the FXC E1/T1 transmission unit 61
Figure 23. Cabling of the FXC RRI transmission unit 62
Figure 24. Cabling of the interface unit 63
Figure 25. Examples of diversity cabling alternatives 65
Figure 26. Routing the cables and closing the cable cover 67
Figure 27. Hanging the BTS cover 70
