Nokia ONT - Page 84

Install
a
G
-
2426G
-
B
indoor
ONT
Connect a UPS to a G-2426G-B ONT
Nokia
ONT
3FE-49441-ABAA-TCZZA
June
2021
Issue 1
84
Figure 6-14 Battery pack onto Power Supply/Charger
Battery Pack Power supply/Charger
Power supply/
Charger
Battery
Pack
36154
4
Plug the 3 prong AC power cord plug end into standard 3 prong AC receptacle rated for 3 prong
AC plug on bottom of power supply/charger as shown in Figure 6-13, “G-2426G-B ONT and PSI
UPS” (p. 83).
5
Plug the AC power cable to AC wall outlet as shown in Figure 6-13, “G-2426G-B ONT and PSI
UPS” (p. 83).
