Chapter 39 Hardware procedures 211

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 58

Multiservice Switch 7460 ESD jack location

Shelf assembly

MSS 3496 001 AC2

ESD jack
