Chapter 39 Hardware procedures 253

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 81

Exploded view of a cable management bracket for a Multiservice Switch 7460

Shelf assembly

PPT 3479 008 AA2

Cable

management

bracket

Captive screw
