Chapter 39 Hardware procedures 285

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 98

A Multiservice Switch 7460 shelf assembly to be installed in a rack

MSS 3479 013 AA2

Rack

Mounting ear

Guide pin

Thread-forming screws
