Chapter 39 Hardware procedures 295

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Procedure job aid

Figure 102

Inserting a power supply in a Multiservice Switch 7440

PPT 3078 003 AA

Locking latch,

open position

Latch
