Figure 104
A power supply of a Multiservice Switch 7460
PPT 3479 002 AA2
Rear view
Front view
Power output
connector
Power input
connector
Grill for airflow,
output side
Power supply
Captive screw
Handle
Status LED
Power switch in the
OFF position
Grill for airflow,
input side
Captive screw
