320 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Figure 114

The external alarm connector of a Multiservice Switch 7460

MSS 3479 015 AA

Alarm 1 for the

external alarm cable

Alarm 2 for the door

alarm cable of a cabinet

1 5

1 9

6 9

6 15

Shelf assembly
