Procedure job aid
Figure 115
Locking and unlocking processor card latches
Unlocked Locked
Locking
latches
Use a 6 mm (1/4-inch) flat-head
screwdriver to lock and unlock
latches.
To unlock, make a 1/4 turn counter-clockwise.
To lock, make a 1/4 turn clockwise.
Note: Do not force a lock too far in
either direction.
