Chapter 39 Hardware procedures 331
Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2
Figure 120
Control processor with BITS faceplate
PPT 3304 001 AA
Ejector latch
Ejector latch
LED status
indicator
Locking latch
DS1/E1 ports
BITS 0 and BITS 1
Port 1
10Base-T Ethernet port
RJ45 connector
Port 3
15-pin
D-type connector
15
8
9
1
V.24 DCE port
Port 2
LED status indicators
for Ethernet port
Pin Numbering
Scheme
