Chapter 39 Hardware procedures 355
Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2
Procedure job aid
Figure 129
Types of cable connectors used on Multiservice Switch processor cards
PPT 3372 001 AA2
Coax - SMB Coax - mini 8W8Coax - BNC
MT-RJ
D-sub with sliding latchD-sub with screws
LC-simplex
SC-simplex
SC-simplex
Top view
Top view
Top view
Top view
End view
End view
End view
End view
Ethernet
RJ-45
