368 Chapter 39 Hardware procedures
NN10600-175 6.1S2
Procedure job aid
Figure 135
Orientation of seismic side panels and seismic cross rails for a Multiservice Switch 7460
PPT 3486 001 AA2
Alignment pin
Seismic cross rail
Seismic side panel
Screw and washer
For thread-forming
screws
To cradle
the rear of
a 7460
