378 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Figure 138

D-sub pinout for BITS cables for DS1 or E1 balanced

PPT 2819 010 AD

To site’s

clock

distribution

panel

5432

9876

pin numbers

Ground

BITSRXN (or BITSRX ring)

BITSRXP (or BITSRX tip)
