Chapter 39 Hardware procedures 381

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 140

Braided shield assembly

PPT 3152 002 AA

Top cover

Connector

Cable

Insert

Cable shield

(folded back)

Bottom cover
