Chapter 39 Hardware procedures 415

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Figure 153

Door alarm connector for a Multiservice Switch 7460

MSS 3479 007 AA

Alarm 1 for the

external alarm cable

Alarm 2 for the door alarm

cable of a cabinet

Mounting ear

Shelf assembly
