438 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Figure 165

Power and alarm panel for rack-mounted alarm panel kit NTPS20BA

MSS 3540 001 AA

Alarm cutoff

Power LEDPower connector

Major alarm LED Alarm cable

connector

Minor alarm LED
