Chapter 39 Hardware procedures 449

Multiservice Switch 7400 Hardware Installation, Maintenance, and Upgrade 6.1S2

Procedure job aid

Figure 168

DC power cables connected to a Multiservice Switch 7420

PPT 3221 012 AA

(+) Battery return

(-) Battery -48V/-60V

Strain relief clip

Ground
