460 Chapter 39 Hardware procedures

NN10600-175 6.1S2

Procedure job aid

Figure 175

Exploded view of a cooling unit and Multiservice Switch 7460

Shelf assembly

Intake airflow

grill

PPT 3479 009 AA2

Cooling unit

Captive screw
