Multiservice Switch 7440, even if you plan to mount termination panels in a
separate rack. A 6.4
cm (2.5 in.) by 42 cm (16.6 in.) opening can
accommodate the cables for a Multiservice Switch
7460.
Ensure that your plan conforms to the cable specifications for the function
processors (FPs) in your device. For more information, see the cable
assembly information in NN10600-170 Nortel Networks Multiservice Switch
7400 Hardware Description.
Figure 13
Floor space requirements for Multiservice Switch cabinets
DCP70056
Door
90°
90°
1.5 m
(5 ft.)
1 m
(3.3 ft.)
1 m
(3.3 ft.)
2.1 m
(7 ft.)
Cabinet Cabinet Cabinet
Cabinet Cabinet Cabinet
Door
Door
90°
90°
Door
